Shim-pack Bio Diol
HPLC Column
Size Exclusion Chromatography Columns
Shim-pack Bio Diol LC 컬럼은 pore size가 다양하게 제공되며, carbohydrates, oligonucleotides, mAb의 aggregates 및 fragments 분석에 효과적입니다.
| Shim-pack Bio Diol | Diol-60 | Diol-120 | Diol-200 | Diol-300 |
|---|---|---|---|---|
| Particle | Silica | |||
| Ligand | Dihydroxypropyl(Diol) | |||
| Particle Size | 3 μm，5 μm | 2 μm，3 μm，5 μm | ||
| Pore Size | 6 nm | 12 nm | 20 nm | 30 nm |
| pH Range | 5.0 - 7.5 | |||
| Molecular Weight Range |
below 10,000 | 1,000 - 100,000 | 5,000 - 300,000 | 20,000 - 1,000,000 |
Features
