Town Gas Analysis

Periodical monitoring of calorific values is necessary to ensure a stable supply of town gas. Since Shimadzu’s system GC is robust and designed for automated analysis, it is widely used for 24 hour/day online analysis in this field.
Dedicated software is able to calculate calorific values and indexes automatically.
Using the sample line selctor SLS-2020, a single system GC can analyse multiple samples without switching the sample line. This saves both running and initial costs.
Town gas analyzer lineup
Model Name | Nexis GC-2030TGA1 | Nexis GC-2030TGA2 | Nexis GC-2030TGA3 | Nexis GC-2030TGA4 |
Type of Detector | TCDx2 | TCD | TCD | TCD |
Target Compounds | H2, O2, N2, CO, CO2, C1, C2, C3 (each min. detection limit: 50 ppm) | O2, N2, CO, CO2, C1, C2, C3 (each min. detection limit: 50 ppm) | H2, O2, N2, CO, CO2, C1, C2, C3 (H2>0.1%, Others>50 ppm) | H2, O2, N2, CO, CO2, C1, C2 (H2>0.1%, Others>50 ppm) |
Analysis Time | 16 minutes | 16 minutes | 10 minutes | 12 minutes |
Others | Full range capability for H2 | - | Good separation between CH4 and CO | Good separation between CH4 and CO |
Application Datasheet | Download |
Download |
Download |
Download |
Applications
Applications | Creation Date |
---|---|
2017-11-17 |
|
2017-11-17 |
|
2017-11-17 |
|
2017-11-17 |
